The Cinco is the most complete veterinary dental system with ergonomic features. Depending on the veterinarian’s preferences, you can adjust the angle of the handpiece console. This feature allows you to place the handpieces at the perfect angle to create the smoothest body movement.
The large shelf offers space to put the different tools needed for the procedure in one place. The rounded edge of the shelf prevents your instruments from falling off. Since there are no joints, seals, or visible screws, it is very easy to clean. The suction hose is flexible and light to prevent any tension on the user’s wrist. In addition, the hose is detachable for easier cleaning.
Included with the Highdent™ Cinco Plus
- Suction
- Air/Water Syringe
- Fiber optic
- 2 High-speed handpieces
- Low-speed handpiece
- Piezo Scaler
- Instrument shelf
- No.1 universal scaling Piezo tip
- No.2 voluminous calculus scaling Piezo tip
- No.10P shallow pockets scaling Piezo tip
Specifications
Air/Water Syringe
- Lightweight, compact contoured head
- Quick connect-disconnect tip
- Uses standard autoclavable tips
- 360º tip rotation
- Precise control of air, water, and mist
Piezo Scaler
- Totally autoclavable and easy to dismantle.
- LED Piezo is available as an option.
Ergonomics
- Simple and easy adjustment of the handpiece console to the desired angle.
Automatic selection of handpieces
- No waste of time selecting the handpiece.
Shelf
- More space for your instruments.
- No joints, seals, or visible screws, for easier cleaning.
- Rounded edge to prevent your instruments from falling.
- 12,5” x 17,5” (32 cm x 44,5 cm).
Suction
- Detachable suction hose for easier cleaning.
- Stronger suction.
- More flexible hose for ease of use.
Adjustable height
- From 31” to 41” (78.7 cm to 104 cm).
Foot control
- Control the handpieces and suction.
- Protective guard.
Muffler
- Highdent™ dental machines include a muffler to reduce noise from the handpieces
Mobile and Secure
- 5.08cm (2”) castors with brakes
Compressor
- The quietest on the market.
- Very easy access to drain valves.
- The fastest oil change in the industry.
- Airflow: 2.1 cubic feet per minute.
110V with oil model
- Amps: 7.0 A
- Power Source: 120 V AC
- Operaring frequency: 50-60 Hz
230V with oil model
- Amps: 4.0 A
- Power Source: 230 V AC
- Operaring frequency: 50-60 Hz
Conforms and Certified
Conforms to UL STD 61010-1
Certified to CSA STD C22.2 No. 61010-1
Intertek No. 4009746
Optional features
- Wall-mount
Download
Wall-mount Dimensions and installation sheet
Optional Colours
Do you find grey and white boring? The Highdent™ Quattro Plus is available in several colours that can brighten your workplace, for a low supplement.
Vibrant
Pink
Innovative
Orange
Passion
Red
Soft
Blue
Fresh
Green
Sunshine
Yellow
Mystery
Purple
Mermaid
Green
Italian
White
Rock
Grey
Ebony
Black
Purchase Guide
You don't know which dental unit to choose
View our Highdent veterinary dental unit purchase guide
