Comprehensive Monitoring Across the Continuum of Care
Quick, easy, and reliable access to respiratory status. It’s the key to help provide safe and effective care — from a patient under sedation during a procedure to monitoring a patient on the general care floor. With a combination of Microstream™ capnography and Nellcor™ pulse oximetry technologies, you can count on the Capnostream™ 35 respiratory monitor to deliver. Continuous monitoring of etCO2, respiration rate, and SpO2. In virtually any clinical setting. It brings certainty where it matters most.
PM35-VET-KIT Contents
- 1x Capnostream™ 35 Portable Respiratory Monitor
- 1x Vet Sensor
- 1x Pulse Oximetry Cable, DOC10
Brochure
General characteristics
- Unit dimensions: 213 mm (h) x 137 mm (w) x 55 mm (d) / (8.38 in (h) x 5.39 in (w) x 2.16 in (d))
- Unit weight : 1 kg. 2.2 lb.
- Input power : 100-240 VAC, 50/60 Hz, ± 10%
Battery
- Battery type : Lithium ion
- Battery pack nominal voltage and energy : 7.2V; 18.72Wh
- Battery operation : Three hours for removable battery pack; 20 minutes for internal battery pack
- Battery charging time : Up to five hours when the monitor is off and up to eight hours when the monitor is on, for both batteries
Microstream™ capnography
- CO2, etCO2 range : 0-150 mmHg
- CO2 accuracy : 0-38 mmHg: ± 2 mmHg / 39-150 mmHg: ± (5% of reading + 0.08 for every 1 mmHg above 38 mmHg)
- Respiration rate range : 0-150 bpm
- Flow rate : 50 (42.5 ≤ flow ≤ 65) ml/minute, flow measured by volume
Nellcor™ pulse oximetry
- SpO2 measurement range : 1-100%
- Pulse rate range : 20 to 250 beats per minute
